Overview Product Description Ergonomics ROPS / FOPS certified. Cabin fully enclosed. The parking brake, work brake and e
Send your inquiryDESCRIPTION
OverviewBasic Info.
| Model NO. | UK-15 |
| Drive Wheel | 4×4 |
| Engine Capacity | 250L |
| Seats | ≤5 |
| Horsepower | 150-250hp |
| Tire Design | Radial |
| Dumping Type | Rear Lifting Style |
| Condition | New |
| Engine | Deutz Bf6m1013ec |
| Optional Engine | Cummins Qsb6.7-C300/Deutz F8l413W/Volvo Tad850ve |
| Turning Radius | 3500 / 6100 mm |
| Tramming Capacity | 15000kg |
| Axle | Metorior Cy-2jeaf/R Rigid Planetary Axle |
| Tire | Aeolus 14.00-24 Pr36 L-5s Tt |
| Transmission | Dana Rt32000 Series |
| Converter | Dana C273 or C313 |
| Wheelbase | 3626mm |
| Box Lift Height | 4248mm |
| Dump Box Volume | 7.5cbm |
| Turning Angle | 45degree |
| Application | Underground Mine |
| Min Ground Clearance | 348mm |
| Overall Size | 7490X2150X2471mm |
| Transport Package | Shipping Container |
| Specification | 15ton |
| Trademark | DALI |
| Origin | Shandong, China |
| HS Code | 8704109000 |
| Production Capacity | 1000 Sets/Year |
Product Description
Product Description
| Capacity | Weight, empty | ||
| Tramming capacity | 15000 kg | Operation weight | 16300 kg |
| Dump box volume | 7.5 m3 | Front axle | 10100 kg |
| Optional box | 8m3 (16000kg) | Rear axle | 6200 kg |
| Main dimension | Weight, loaded | ||
| Overall size | 7490X2150X2471 mm | Fully loaded weight | 31300 kg |
| Box lift height | 4248 mm | Front axle | 15200 kg |
| Wheelbase | 3626 mm | Rear axle | 16100 kg |
| Min. ground clearance | 348 mm | Speed | |
| Turning radius | 3500 / 6100 mm | 1st gear | 0~4.5 km/h |
| Turning angle | 45° | 2nd gear | 0~9.8 km/h |
| Dump angle | 60° | 3rd gear | 0~17.8 km/h |
| Dump box motion time | 4th gear | 0~23.5 km/h | |
| Discharging time | ≤13s | ||
| Box lowering time | ≤10s | ||
| POWER TRAIN | |||
| Engine | Transmission | ||
| Diesel engine | DEUTZ BF6M1013EC | Brand | DANA |
| Output | 165kw @ 2300rpm | Model | RT32000 |
| Max. torque | 854 Nm @ 1400rpm | Axle | |
| Displacement | 7.2 L | Model | DANA 16D2149 |
| Emission norms | EU II, US T2 | Type | Rigid planetary axle |
| Converter | Tire | 14.00-24 L-5S TT | |
| Brand | DANA | ||
| Model | C273 or C313 | ||
1. Are you a factory or trade company?We are a manufacturer, we also supply trade service.2. Will you provide some wearing parts of the machines?Yes, of course. We ship them with the machine and spare parts in wooden boxes.3. How is the quality of your products?We have been approved by ISO and CE, and always produce our products strictly according to national and international standards. We do strict inspections in every production stage, and all the machines we sell are under warranty.4. What about your price?We always supply our products at a reasonable price to build long-term business and earn a good reputation.5. What payments term do you accept?We accept L/C, T/T, and other ways like D/A and D/P, etc, T/T goes with 30% advanced payment after signing the contract or order confirmation.6. What about the order lead time?We have two factories and big productivity, the order lead time is only 15-20 days.
How to Choose the Right Underground Mining Truck
What Is an Underground Mining TruckAn underground mining truck is a machine that is used to transport coal, ore, and other minerals from an underground mine to the surface. Different types of underground mining trucks are used for different applications.
What Is an Articulated Underground Mining Truck
This truck has two sections that hinge together, giving it more flexibility than the rigid frame truck. It can travel over more uneven ground, but it's also more prone to tipping over.
Factors to Consider When Choosing an Underground Mining Truck
When choosing an underground mining truck, there are a few factors you'll need to take into account. The most important of these is the size and weight of the truck.
You'll also need to decide on the power source: diesel, gasoline, or electric. And finally, you'll need to decide on the features you require, such as hazardous-area lighting, reverse alarm, and air conditioning.
The Benefits of Underground Mining Trucks
When it comes to mining, one of the most important things you need to consider is how you're going to get the ore out of the ground. And that's where underground mining trucks come in.
Underground mining trucks are specifically designed to move large amounts of ore and waste material quickly and efficiently. And because they're made to withstand the tough conditions of an underground mine, they're also built to last.
Another benefit of underground mining trucks is that they can be fitted with a variety of attachments, which makes them even more versatile. For example, you can add a rock drill or a hydraulic breaker to help with the mining process.
So if you're looking for a truck that can help make your mining operation more efficient, then an underground mining truck is the way to go.
How to Choose the Right Underground Mining Truck for Your Needs
Now that you know all about the different types of underground mining trucks, it's time to choose the right one for your needs. Here are a few things to keep in mind when making your selection:
What is the payload capacity of the truck? This is important because you need to make sure the truck can handle the weight of the material you're hauling.
What is the towing capacity of the truck? This is important if you're planning on using the truck to tow a trailer.
What is the ground clearance of the truck? This is important because you need to make sure the truck can clear obstacles in its path.
What is the turning radius of the truck? This is important because you need to be able to maneuver the truck in tight spaces.
Keep these factors in mind and you'll be sure to choose the right underground mining truck for your needs.
Advantages of Dali Underground Mining Truck
1.The updated DALI underground truck features low overall weight with the high payload and ramp speeds for enhanced productivity.
2.The dumper features wear resistant steel structure to meet productivity needs in a rough mining environment and high ambient temperatures.
3.World class engines are optional for the underground dumper. Such as DEUTZ, VOLVO, CUMMINS, BENZ, etc. which can meet different emission requirement in different region.
4.All DALI underground mining trucks are designed to operate fully loaded and at high speeds on long spiral haulage ways with up to 25 percent gradients.
5.Specifically designed to perform in tough underground conditions. The engine with low fuel consumption, new heavy-duty axles, FEA optimized steel frame and a reliable and easy to maintain hydraulic system Narrow size enables operation in headings as small in its class.
6.Ground-level daily maintenance enables safer servicing.
7.For all DALI underground mine trucks, ejector box is optional for tight backfill haulage.
8.The standard manual central lubrication system optimizes grease consumption and extends the life of the bushes and bearings. Auto lubrication system is optional, Activated by DALI Intelligent Control System when the parking brake is released, hard to reach areas are well lubricated and service time is reduced.
9.High engine peak torque and torque rise allow less downshifting and better acceleration, while the new transmission automatic gear shifting and torque converter lock-up ensure fast speeds. High power and low engine torque rpm improve fuel economy and reduce noise.
10.Catalytic purifier with muffler, EOC+POC design, which reduce the air pollution underground.
11.Designed with operator and maintenance safety in mind, the cabin is ROPS/FOPS certified.
12.Wet SAHR braking at end of each wheel, combination design of working brake, parking brake and emergency brake.
13.Different dump boxes are designed with extra volume when selecting the right box for the broken material density.
14.The reinforced steel structure uses wear resistant steel for extended box lifetime. The wide range of box options includes an ejector box for backfilling and unloading in areas of restricted dump height. Further, a tailgate option which is available for all box sizes improves productivity and reduces spillage.
15.Standard features improving safety include lockable main switch, articulation lock and box maintenance support, among others. DALI Intelligent Control System monitors the equipment health and provides early warnings. The control system user interface is available in multiple different languages, according to the customer needs.
